Gallagher M160 Electric Fence Energizer for Electric Fences.

User-friendly 230V energizer for shorter fences up to 8 km. Easy to install using its wall clamp.

Advantages:

Easy to install and use
Sturdy connection terminals

Specifications:

Animals: Dog. Cat, Rabbit, Bird, Stone martens, Herons
Max. output voltage (V): 7000
Charging energy (J): 1.2
Maximum pulse energy (J): 0.65
Number of earth rods required: 2 x 1 m
Multiple wires Distance – perfect conditions (km): 8
Multiple wires Distance – light vegetation (km): 3
Multiple wires Distance – recommended (km): 1.2
Fenced area (ha) (recommendation): 4
Maximum output voltage (V): 6800
Voltage at 500 Ohm load (V): 3800
Load voltage 100 Ohm (V): 1300
Charging energy (J): 1.4
Maximum pulse energy (J): 0.47
Single wire - ideal conditions (km): 30
Distance with multiple wires (2) - ideal conditions (km): 8
Distance with multiple wires (2) - Light vegetation (km): 3
Distance with multiple wires (3) - Recommended (km): 2
Enclosure boundary (Ha/Acre): 4/10
Average power consumption (W): 0.9
Alarm indicator LED Earth voltage: No
LED bar graph: No
12V battery backup: Optional
Adaptive control: No
Delay with load (time delay): No
Short circuit safety: No
Built-in lightning arrester: Yes
Recommended number of earth stakes (not included): 2x1m
European standard: EN60335 -2-76-A11
IPX rating: IPX4
Warranty: 3 years
Dimensions (lxwxh mm): 145x75x170
Weight (kg): 0.87
Color: Black/Orange
Display (LED/LCD): No
Vegetation: Normal
Recommended without vegetation (km): 6-10
